Our Filter Modules and Filter Module Boxes are a low cost solution for research and signal conditioning applications such as anti-aliasing in digital signal processing, separating specific bandwidths of information, enhancing signal-to-noise ratio, low noise pre-amplification and more. The filter modules plug-into various chassis and FMB series of boxes or can be used as a component in a pc design.
FMB3002 Filter Picture Open
FMB3002 Filter Picture
• Choice of 1 or 2 Channel
• Choice of Fixed Frequency from 1Hz to 1MHz
• Choice of 4-Pole, 8-Pole and 16-Pole
• Choice of Butterworth and Bessel
• Optional Pre and Post Filter Gain
• Choice of AC Powered or DC Powered
• Choice of Single-Ended or Differential Input
• BNC and Terminal Block Connections
• Mix and Match Modules
• Accepts Krohn-Hite 3F Modules Only
Model FMB3002
Filter Modules Picture
• Choice of 3A, 3B, 3C and 3D Module Packages
• Choice of Fixed Frequency from 1Hz to 1MHz
• Choice of 1-Pole to 8-Pole and 16-Pole
• Choice of Butterworth and Bessel
• Choice of Pre and Post Filter Gain
• Choice of Single-Ended or Differential Input
Module General Specifications
Fixed between 1Hz and 2MHz, Single-Ended, Low-Pass
Fixed between 1Hz to 1MHz, Differential (no gain), Low-Pass

Fixed between 1Hz and 600kHz, Single-Ended, High-Pass
Fixed between 1Hz to 200kHz Differential (no gain), High-Pass
Model 3A, 3B, 3C and 3D Filter Modules
3A Module Box Picture
3B Module Box Picture
3C Module Box Picture
3D Module Box Picture
